Belt Conveyor

Belt Conveyor

Belt Conveyor

Type: Transport loose materials or pieces

Feed Size: ≤250 mm

Capacity: 20-600 t/h

Materials: Limestone, granite, river pebble, basalt, coal, Iron Ore etc.

Applications: transportation and production lines of cement, mining, metallurgy, chemical, foundry, building materials

Overview

Belt Conveyors, using friction transmission principle for moving, can be used for connecting different equipments of the plants. It realizes continuous and automated operation of the production line and improves the production efficiency and reduces labour intensity.

Technical Data

Belt Width(mm) Belt Length(m) -- Power(m/w) Transmission Speed(m/s) Capacity(t/h)
400 0~12--1.5 12~20--2.2~4 20~25--4~7.5 1.3~1.6 40~80
500 0~12--3 12~20--4~5.5 20~30--5.5~7.5 1.3~1.6 78~191
650 0~12--4 12~20--5.5 20~30--7.5~11 1.3~1.6 131~323
800 0~6--4 6~15--5.5 15~30--7.5~15 1.3~1.6 278~546
1000 0~10--5.5 10~20--7.5~11 20~40--11~22 1.3~2.0 435~853
1200 0~10--7.5 10~20--11 20~40--15~30 1.3~2.0 655~1284
